Crestron CP4: 4-Series Control System
Model CP4
Request a Quote
Availability: Out of Stock
- 4-Series control system, 2 GB SDRAM and 8 GB flash
- Eight relays, eight Versiport I/O and eight IR/serial ports
- Up to 10 programs running at once
- Gigabit Ethernet with enterprise-class security and SNMP V3
Product Overview
Overview
The Crestron CP4 is a 4-Series control system with an embedded multicore processor, 2 GB SDRAM and 8 GB flash memory. It has onboard IR/serial, COM, I/O, relay, Cresnet and gigabit Ethernet control ports in a 1 RU rack-mountable chassis.
Corporate AV supplies, programs and commissions Crestron control systems across India for meeting rooms, boardrooms and venues, with the touch screens, switching and audio around them. Request a quote for supply, installation and commissioning.
Key features
- 4-Series control engine with 2 GB SDRAM and 8 GB flash memory
- Onboard IR/serial, COM, I/O, relay, Cresnet and gigabit Ethernet control ports
- Runs up to 10 programs at the same time
- Control from iPhone, iPad and Android apps, plus XPanel computer and web control
- Enterprise-class network security, SNMP V3 remote IT management and native BACnet/IP
- Crestron Fusion room monitoring and XiO Cloud provisioning support
- USB 2.0 host port and a rear memory card slot, 1 RU rack mountable
Why choose the CP4
It puts a multicore 4-Series control engine, eight relays, eight I/O ports and eight IR/serial ports into one rack unit, with enterprise-class network security and cloud provisioning. It can run up to ten programs at once.
Product Highlights
Key Benefits
4-Series control system, 2 GB SDRAM and 8 GB flash
Eight relays, eight Versiport I/O and eight IR/serial ports
Up to 10 programs running at once
Gigabit Ethernet with enterprise-class security and SNMP V3
1 RU rack mount, power pack included
Use Cases
Ideal Applications
Boardrooms
Meeting Rooms
Auditoriums
Technical Details
Technical Specifications
Control engine and memory
Control engine
Crestron 4-Series, real-time preemptive multithreaded kernel, up to 10 simultaneous programs
SDRAM
2 GB
Flash
8 GB
Memory card
SD and SDHC up to 32 GB
External storage
USB mass storage devices up to 1 TB
Control ports
Relays
(8) normally open isolated relays, 1 A at 30 VAC/VDC
I/O
(8) Versiport digital input/output or analog input ports
IR/serial
(8) IR output ports up to 1.2 MHz, or 1-way serial TTL/RS-232
COM
COM 1 RS-232/422/485, COM 2 and COM 3 RS-232, up to 115.2k baud
Network
(1) 100/1000Base-TX Ethernet, (1) Cresnet master port
Power and physical
Power pack (included)
PW-2420RU, 100-240 VAC input, 24 VDC at 2.5 A output
Power consumption
15 W (excluding connected Cresnet devices)
Mounting
Freestanding or 1 RU 19 in. rack mount (adhesive feet and rack ears included)
Dimensions
1.70 in. (44 mm) high without feet, 17.28 in. (439 mm) wide, 6.56 in. (167 mm) deep
Weight
3.12 lb (1.42 kg)
Operating temperature
41 to 113 degrees F (5 to 45 degrees C)
In The Box
What's Included
PW-2420RU power pack
Rack ears and adhesive feet
Why CorporateAV?
Sourced right. Installed right.
Genuine Manufacturer Stock
Every unit sourced through authorized distribution, backed by manufacturer warranty.
Expert AV Integration
Paired correctly with compatible systems and your room's existing AV infrastructure.
Pan-India Delivery & Support
On-site installation and ongoing technical support wherever your project is based.
More Details
Additional Information
Why Buy The CP4 From Corporate AV?
- Genuine Crestron Electronics stock with manufacturer warranty support
- Custom pricing for bulk and multi-room / multi-site rollouts
- Local after-sales support — a real team you can call or WhatsApp, not a call centre
- Expert guidance on product selection and deployment planning
- Professional installation across Bangalore, Hyderabad, Mumbai, Delhi NCR, and the wider India region
Distribution
Corporate AV supplies and installs Crestron Electronics products across Bangalore, Hyderabad, Mumbai, Delhi NCR, Chennai, Pune, Kolkata, Ahmedabad, and the wider India region.
Frequently Asked Questions
What is the Crestron CP4?
The Crestron CP4 is a 4-Series control system with an embedded multicore processor, 2 GB SDRAM and 8 GB flash memory, in a 1 RU rack-mountable chassis.
What control ports does the CP4 have?
Crestron lists eight normally open relays, eight Versiport I/O ports, eight IR/serial ports, one RS-232/422/485 COM port, two RS-232 COM ports, a Cresnet master port and a gigabit Ethernet LAN port.
How many programs can the CP4 run?
Crestron lists support for up to 10 simultaneously running programs on the CP4.
How secure is the CP4?
Crestron lists enterprise-class network security and authentication, including IEEE 802.1X, Active Directory authentication, FIPS 140-2 compliant encryption, SNMP V3 and HTTPS web setup.
Does the CP4 support BACnet and cloud management?
Yes. Crestron lists native BACnet/IP support, Crestron Fusion room monitoring and scheduling, and XiO Cloud provisioning and management.
How is the CP4 mounted and powered?
It is freestanding or mounts in 1 RU of a 19 in. rack, with adhesive feet and rack ears included. The included PW-2420RU power pack supplies 24 VDC, or the CP4 can be powered over Cresnet.
What is the Crestron part number for the CP4?
Crestron lists the material number for the CP4 as 6511816.
