Crestron DM-NVX-D30: 4K60 4:4:4 HDR Network AV Decoder
Model DM-NVX-D30
Request a Quote
Availability: Out of Stock
- 4K60 4:4:4 decoder over standard Gigabit Ethernet
- HDR10, HDR10+ and Dolby Vision, HDCP 2.3
- One HDMI output, analog audio output and AES67 audio
- PoE+ powered, optional 24 VDC power pack
Product Overview
Overview
The Crestron DM-NVX-D30 is a DM NVX network AV decoder that receives 4K60 4:4:4 video with HDR10, HDR10+ and Dolby Vision over standard Gigabit Ethernet. It has one HDMI output, an analog audio output, AES67 audio and PoE+ powering in a compact surface-mountable unit.
Corporate AV designs, supplies and commissions Crestron DM NVX AV over IP systems across India, with the encoders, network switching and control around them. Request a quote for supply, installation and commissioning.
Key features
- 4K60 4:4:4 video decoding over standard Gigabit Ethernet
- HDR10, HDR10+ and Dolby Vision support with Pixel Perfect Processing
- Enterprise-grade security including 802.1X, Active Directory credential management, TLS and AES-128
- HDCP 2.3 compliant, one HDMI output with image preview and background image
- Analog audio de-embedding, 7.1 surround sound and AES67 audio
- Copper Ethernet with PoE+ support and automatic point-to-point connectivity
- Managed through DM NVX Director appliances, XiO Cloud and .AV Framework, compact surface-mountable design
Why choose the DM-NVX-D30
It is the receiving end of a DM NVX AV over IP system: 4K60 4:4:4 HDR video over ordinary Gigabit Ethernet, powered by PoE+, with enterprise-grade security built in. It decodes streams from DM NVX encoders and fits into a compact surface-mount unit.
Product Highlights
Key Benefits
4K60 4:4:4 decoder over standard Gigabit Ethernet
HDR10, HDR10+ and Dolby Vision, HDCP 2.3
One HDMI output, analog audio output and AES67 audio
PoE+ powered, optional 24 VDC power pack
Compact, surface-mountable, 1.7 lb (0.77 kg)
Use Cases
Ideal Applications
Control Rooms
Auditoriums
Campus AV Distribution
Technical Details
Technical Specifications
Video
Maximum resolution
4096 x 2160 at 60 Hz, 4:4:4 color sampling
HDR
HDR10, HDR10+, Dolby Vision, Deep Color
Output
(1) HDMI Type A female, HDCP 2.3, DVI compatible
Decoding
Pixel Perfect Processing or DM-NVX-E10/E20 Series streams, multicast via secure RTSP
Audio
Digital formats
Dolby Digital, Dolby TrueHD, Dolby Atmos, DTS, DTS:X and LPCM up to 8 channels
Analog output
Stereo 2-channel, 4 Vrms balanced or 2 Vrms unbalanced maximum
AES67
24-bit 48 kHz transmit and receive
Network and control
Ethernet
100/1000 Mbps, TCP/IP, UDP/IP, CIP, DHCP, SSL, TLS, SSH, SFTP, IEEE 802.1X, IPv4 and IPv6
Device control
RS-232, IR/serial and CEC, with HTTPS web setup
Power over Ethernet
IEEE 802.3at Type 2 PoE+ Class 4 (25.5 W)
Optional power pack
PW-2412WU, 24 VDC, 1.25 A (sold separately)
Physical
Mounting
Freestanding, surface mount, or attach to a single rack rail
Dimensions
5.41 in. (138 mm) high, 9.27 in. (236 mm) wide, 1.15 in. (30 mm) deep
Weight
1.7 lb (0.77 kg)
Operating temperature
32 to 104 degrees F (0 to 40 degrees C)
Why CorporateAV?
Sourced right. Installed right.
Genuine Manufacturer Stock
Every unit sourced through authorized distribution, backed by manufacturer warranty.
Expert AV Integration
Paired correctly with compatible systems and your room's existing AV infrastructure.
Pan-India Delivery & Support
On-site installation and ongoing technical support wherever your project is based.
More Details
Additional Information
Why Buy The DM-NVX-D30 From Corporate AV?
- Genuine Crestron Electronics stock with manufacturer warranty support
- Custom pricing for bulk and multi-room / multi-site rollouts
- Local after-sales support — a real team you can call or WhatsApp, not a call centre
- Expert guidance on product selection and deployment planning
- Professional installation across Bangalore, Hyderabad, Mumbai, Delhi NCR, and the wider India region
Distribution
Corporate AV supplies and installs Crestron Electronics products across Bangalore, Hyderabad, Mumbai, Delhi NCR, Chennai, Pune, Kolkata, Ahmedabad, and the wider India region.
Frequently Asked Questions
What is the Crestron DM-NVX-D30?
The Crestron DM-NVX-D30 is a network AV decoder from the DM NVX family. It receives 4K60 4:4:4 video with HDR over standard Gigabit Ethernet and outputs it on one HDMI connector.
What resolution does the DM-NVX-D30 support?
Up to 4096 x 2160 at 60 Hz with 4:4:4 color sampling, with HDR10, HDR10+, Dolby Vision and Deep Color support. Custom resolutions are supported at pixel clock rates up to 600 MHz.
How is the DM-NVX-D30 powered?
It is powered by PoE+ (IEEE 802.3at Type 2, Class 4, 25.5 W). Alternatively, an optional PW-2412WU 24 VDC power pack, sold separately, can be used. Typical power consumption is 16 W.
What cabling does 4K60 4:4:4 HDR need?
Crestron states that 4K60 4:4:4 and HDR require HDMI cables and couplers with a minimum TMDS bandwidth of 18 Gbps. Bandwidth loss adds up across cables and couplers.
How secure is the DM-NVX-D30?
Crestron lists enterprise-grade security including 802.1X, Active Directory credential management, TLS and AES-128 encryption with PKI authentication, and HDCP 2.3.
How is the DM-NVX-D30 controlled and managed?
It is set up through built-in web pages and works with a Crestron 3-Series or later control system. Crestron also lists DM NVX Director, XiO Cloud, .AV Framework and Crestron Home OS support.
What is the Crestron part number for the DM-NVX-D30?
Crestron lists the material number for the DM-NVX-D30 as 6511507.
