LG 55EW5TK-A: 55 Inch Transparent OLED Touch Signage Display
Model 55EW5TK-A
Request a Quote
Availability: Out of Stock
- 55 inch transparent OLED panel with 33 percent transparency
- Self lighting OLED pixels with no backlight, 400 nit brightness and 150,000:1 contrast
- P-Cap multi touch with up to 10 simultaneous points and anti fingerprint tempered glass
- Ultra slim 7.4mm panel depth in a semi assembled design
Product Overview
Overview
The LG 55EW5TK-A is a transparent OLED touch signage display that lets background objects remain visible through vivid on screen content, built for retail, museum, and hospitality environments.
Specification highlights for the 55EW5TK-A: Panel Technology: OLED Self-Lighting Pixels, No Backlight; Native Resolution: 1920 x 1080 Full HD; Brightness: 150 nit APL 100% / 400 nit APL 25% without Glass. Corporate AV supplies and integrates the 55EW5TK-A across India for retail and exhibition projects, including site survey, installation and commissioning where the project needs it.
Key features
- 55 inch transparent OLED panel with 33 percent transparency
- Self lighting OLED pixels with no backlight, 400 nit brightness and 150,000:1 contrast
- P-Cap multi touch with up to 10 simultaneous points and anti fingerprint tempered glass
- Ultra slim 7.4mm panel depth in a semi assembled design
- webOS 4.0 platform with embedded content management system
Why choose the 55EW5TK-A
It is a transparent OLED display, so content floats over the glass without hiding the product or space behind it. Corporate AV checks the room, mounting surface, power and network during a site survey, so the 55EW5TK-A is installed and commissioned as part of a complete AV system rather than delivered as a box.
Product Highlights
Key Benefits
55 inch transparent OLED panel with 33 percent transparency
Self lighting OLED pixels with no backlight, 400 nit brightness and 150,000:1 contrast
P-Cap multi touch with up to 10 simultaneous points and anti fingerprint tempered glass
Ultra slim 7.4mm panel depth in a semi assembled design
webOS 4.0 platform with embedded content management system
Use Cases
Ideal Applications
Retail Stores & Malls
Exhibitions & Events
Hotels & Hospitality
Technical Details
Technical Specifications
Display
Panel Technology
OLED Self-Lighting Pixels, No Backlight
Screen Size
55 Inches
Native Resolution
1920 x 1080 Full HD
Aspect Ratio
16:9
Refresh Rate
120Hz
Brightness
150 nit APL 100% / 400 nit APL 25% without Glass
Contrast Ratio
150,000:1
Color Gamut
BT709 120%
Color Depth
1.07 Billion Colors 10-bit
Response Time
1ms G to G / 8ms MPRT
Viewing Angle H x V
178 x 178 Degrees
Surface Treatment
Hard Coating 2H Anti-Glare Anti-Fingerprint
Orientation Support
Portrait and Landscape
Bezel Width
7.9mm Top Right Left / 144.5mm Bottom
Bezel Color
Matt Silver
Touch & Interaction
Touch Technology
P-Cap Projected Capacitive Touch
Touch Points
Maximum 10 Points Multi-Touch
Touch Response Time
120ms or Less
Touch Accuracy
3.5mm
Touch Interface
USB 2.0
Touch Protection Glass
3.0T Tempered Anti-Glare Anti-Fingerprint
Touch Glass Transmission
84% Typical
Processing & Software
Operating System
webOS 4.0
Internal Memory
16GB
Content Management
Embedded CMS with Local Content Scheduling and Group Manager
Software Compatibility
LG SuperSignCMS, SuperSignControl, SuperSignMedia Editor, LG ConnectedCare
Smart Features
USB Plug and Play, Fail Over, Video Tag, Screen Rotation, Gapless Playback, SNMP, Auto Set ID, Wake on LAN, HDMI-CEC, Pro:Idiom, Status Mailing
Connectivity & Expansion
Output Connectivity
DisplayPort Out, Audio Out, Touch USB 2.0 Type B, RS-232C Out with IR Out, RJ45 LAN
Physical, Mounting & Compatibility
Weight Head Panel
12.9 kg
Weight Signage Box
3.4 kg
Operation, Power & Environment
Operation Hours
18 Hours per Day 7 Days per Week Moving Content Only
Power Supply
AC 100 to 240V 50/60Hz Built-In
Power Consumption Typical
280W
Power Consumption Max
300W
Operating Temperature
0 to 40 Degrees Celsius
General
Brand and Model
LG 55EW5TK-A Transparent OLED Touch Signage
Transparency
33% Typical with P-Cap Touch Film
OS Support for Touch
Windows 8.1 and Windows 10
Input Connectivity
HDMI HDCP 1.4, DisplayPort HDCP 1.3, RS-232C In, RJ45 LAN, IR In, USB 2.0 Type A x2
Third Party Compatibility
Crestron Connected Certified
Panel Dimensions W x H x D
1225.5 x 832.9 x 7.4mm Head Panel
Signage Box Dimensions W x H x D
782.8 x 238.4 x 34.7mm
Operating Humidity
10% to 80%
EMC Certification
FCC Class A / CE / KC
Safety Certification
IEC 60950-1 / EN 60950-1 / UL 60950-1
Why CorporateAV?
Sourced right. Installed right.
Genuine Manufacturer Stock
Every unit sourced through authorized distribution, backed by manufacturer warranty.
Expert AV Integration
Paired correctly with compatible systems and your room's existing AV infrastructure.
Pan-India Delivery & Support
On-site installation and ongoing technical support wherever your project is based.
More Details
Additional Information
Why Buy The 55EW5TK-A From Corporate AV?
- Genuine LG stock with manufacturer warranty support
- Custom pricing for bulk and multi-room / multi-site rollouts
- Local after-sales support — a real team you can call or WhatsApp, not a call centre
- Expert guidance on product selection and deployment planning
- Professional installation across Bangalore, Hyderabad, Mumbai, Delhi NCR, and the wider India region
Distribution
Corporate AV supplies and installs LG products across Bangalore, Hyderabad, Mumbai, Delhi NCR, Chennai, Pune, Kolkata, Ahmedabad, and the wider India region.
Frequently Asked Questions
How bright is the LG 55EW5TK-A?
LG lists the brightness of the 55EW5TK-A as: 150 nit APL 100% / 400 nit APL 25% without Glass.
What resolution does the LG 55EW5TK-A have?
LG lists the resolution of the 55EW5TK-A as: 1920 x 1080 Full HD.
What panel does the LG 55EW5TK-A use?
LG lists the panel of the 55EW5TK-A as: OLED Self-Lighting Pixels, No Backlight.
What operating hours is the LG 55EW5TK-A designed for?
LG lists the operating hours of the 55EW5TK-A as: 18 Hours per Day 7 Days per Week Moving Content Only.
What operating system or platform does the LG 55EW5TK-A run?
LG lists the platform of the 55EW5TK-A as: webOS 4.0.
Does Corporate AV install the LG 55EW5TK-A?
Yes. Corporate AV can supply the 55EW5TK-A only, or deliver it turnkey with site survey, mounting, cabling and commissioning. See our AV installation services for how a project is run.
How do I get a quote for the LG 55EW5TK-A in India?
Use the Request a Quote button on this page or message Corporate AV on WhatsApp. Pricing depends on quantity, delivery location and installation scope, so we prepare a tailored proposal rather than publishing a fixed price.
