Dahua PKP-KB0A: Document Camera
Model PKP-KB0A
Request a Quote
Availability: Out of Stock
- Auto-Focus Technology: Ensures sharp images without manual adjustments, saving you time during sessions
- Flexible Multi-Angle Arm: Easily adjusts to various positions for optimal viewing and demonstration
- USB Plug-and-Play: Simple connection to laptops and PCs for immediate use without the need for drivers
- Compact and Lightweight Design: Portable and easy to set up, perfect for classrooms, offices, and home use
Product Overview
Overview
The Dahua PKP-KB0A is a document camera. With its advanced high-resolution imaging capabilities, this document camera delivers crisp visuals for documents, textbooks, and 3D objects. The PKP-KB0A features an intuitive design for easy operation, making it ideal for educators, business professionals, and remote workers.
Corporate AV supplies, installs and supports the Dahua PKP-KB0A across India. Request a quote for supply, installation and commissioning.
Key features
- High-Resolution Imaging - Captures documents and objects in stunning detail for clear and impactful presentations.
- Auto-Focus Technology - Ensures sharp images without manual adjustments, saving you time during sessions.
- Flexible Multi-Angle Arm - Easily adjusts to various positions for optimal viewing and demonstration.
- USB Plug-and-Play - Simple connection to laptops and PCs for immediate use without the need for drivers.
- Compact and Lightweight Design - Portable and easy to set up, perfect for classrooms, offices, and home use.
- Real-Time Annotation - Supports live writing and drawing directly over displayed content for dynamic interaction.
- Zoom Functionality - Optical and digital zoom to magnify details for enhanced visual clarity.
- Versatile Compatibility - Works seamlessly with Windows, Mac, and major video conferencing platforms.
Why choose the PKP-KB0A
It is a USB camera for adding video calling to a room or an interactive display. Corporate AV adds a site survey, installation and support across India, so the PKP-KB0A is specified and installed for your space and not just shipped.
Product Highlights
Key Benefits
Auto-Focus Technology: Ensures sharp images without manual adjustments, saving you time during sessions
Flexible Multi-Angle Arm: Easily adjusts to various positions for optimal viewing and demonstration
USB Plug-and-Play: Simple connection to laptops and PCs for immediate use without the need for drivers
Compact and Lightweight Design: Portable and easy to set up, perfect for classrooms, offices, and home use
Use Cases
Ideal Applications
Huddle rooms and small meeting rooms
Classrooms and training rooms
BYOD video calls with Teams, Zoom and Google Meet
Technical Details
Technical Specifications
Media functions
Illuminator
5 adjustable brightness levels
Gestures
Supports moving images with your fingers, scaling with 2 fingers and erasing with the swiping gesture.
Annotation
6 selectable colors
Eraser
3 eraser sizes and one-click clear page
Rotation
Supports rotating the screen 90 degrees with one click.
Images are automatically optimized after switching to the AI photo function (the tablet device should be connected to the booth)
Aerial View
Supports displaying images on the whiteboard and navigating within large images.
Minimization
Windows can be minimized.
Connectivity
USB Port
1 × USB-A (USB 2.0)
Other specifications
Category
Conferencing Camera, Dahua
Camera
Photographing Area
A4
Focus Mode
AF auto focus
White Balance
Auto adjustment
Color Compensation Mode
Auto adjustment
Imaging Distance
150 mm–260 mm
Total Pixels
13 MP
Effective Pixels
13 MP
Video Output Format
MJPG, YUV2 (third-party software)
Maximum Output Frame Rate
4168 × 3126/10 fps
Default Output Resolution
4168 × 3126
Power Supply
USB
Voltage
5 VDC
Power Consumption
≤2.5 W
Standby Power Consumption
≤0.25 W
Operating Temperature
–15 °C to +45 °C (+5 °F to +113 °F)
Storage Temperature
–20 °C to +60 °C (–4 °F to +140 °F)
Operating Humidity
0%–93%, 101 KPa
Storage Humidity
0%–95%, 101 KPa
Product Dimensions
When open, 388 mm × 385 mm × 270 mm (15.28" × 15.16" × 10.63"); When closed, 380 mm × 70 mm × 270 mm (14.96" × 2.76" × 10.63")
Net Weight
1.45 kg (3.20 lb)
Installation Method
Wall mount
Packing List
4 × expansion glue plugs, 4 × expansion bolts, 1 × USB connection cable, 1 × video booth, 1 × quality certificate, 1 × cable cover, 1 × wall-mount box, 2 × cable cover screws, 4 × PE wall-mounted bracket screws, 2 × glue plugs, 2 × keys
Why CorporateAV?
Sourced right. Installed right.
Genuine Manufacturer Stock
Every unit sourced through authorized distribution, backed by manufacturer warranty.
Expert AV Integration
Paired correctly with compatible systems and your room's existing AV infrastructure.
Pan-India Delivery & Support
On-site installation and ongoing technical support wherever your project is based.
More Details
Additional Information
Why Buy The PKP-KB0A From Corporate AV?
- Genuine Dahua stock with manufacturer warranty support
- Custom pricing for bulk and multi-room / multi-site rollouts
- Local after-sales support — a real team you can call or WhatsApp, not a call centre
- Expert guidance on product selection and deployment planning
- Professional installation across Bangalore, Hyderabad, Mumbai, Delhi NCR, and the wider India region
Distribution
Corporate AV supplies and installs Dahua products across Bangalore, Hyderabad, Mumbai, Delhi NCR, Chennai, Pune, Kolkata, Ahmedabad, and the wider India region.
Frequently Asked Questions
What is the Dahua PKP-KB0A?
The Dahua PKP-KB0A is a document camera. With its advanced high-resolution imaging capabilities, this document camera delivers crisp visuals for documents, textbooks, and 3D objects. The PKP-KB0A features an intuitive design for easy operation, making it ideal for educators, business professionals, and remote workers.
Who is the Dahua PKP-KB0A best suited for?
The PKP-KB0A suits huddle rooms and small meeting rooms, classrooms and training rooms, byod video calls with teams and zoom and google meet. Corporate AV can advise whether it is the right fit for your space.
Can Corporate AV supply multiple Dahua PKP-KB0A units for a rollout?
Yes. Corporate AV supplies and integrates the Dahua PKP-KB0A in single units and multi-room rollouts across India, with a site survey, installation, commissioning and support.
How do I get a quote for the Dahua PKP-KB0A in India?
Use the Request a Quote button on this page or contact Corporate AV with your room details and quantity, and a consultant will respond with a quotation for supply and installation.
What are the key specifications of the Dahua PKP-KB0A?
These key specifications are listed for the Dahua PKP-KB0A. Power Consumption: ≤2.5 W. Storage Temperature: –20 °C to +60 °C (–4 °F to +140 °F). Storage Humidity: 0%–95%, 101 KPa. Photographing Area: A4. Focus Mode: AF auto focus.
