Newline TT-7523C: 75 Inch C Series 4K Interactive Display
Model TT-7523C
Request a Quote
Availability: Out of Stock
- Resolution: 3840 x 2160 (4K)
- Brightness: 400 cd/m2 (center)
- Touch Technology: Infrared
- Touch Points: 40 on Windows
Product Overview
Overview
The Newline TT-7523C is a 75 inch c series 4K interactive display. Newline's own specification sheet lists the panel, touch, system and connection details below.
Corporate AV supplies, installs and supports the Newline TT-7523C across India. Request a quote for supply, installation and commissioning.
Key features
- Resolution: 3840 x 2160 (4K)
- Brightness: 400 cd/m2 (center)
- Touch Technology: Infrared
- Touch Points: 40 on Windows
- Operating System: None embedded (no Android)
- Processor: Arm Cortex-A55 x 4
Why choose the TT-7523C
It is an interactive display built for presenting, annotating and collaborating on one large touch screen. Corporate AV adds a site survey, installation and support across India, so the TT-7523C is specified and installed for your space and not just shipped.
Product Highlights
Key Benefits
Resolution: 3840 x 2160 (4K)
Brightness: 400 cd/m2 (center)
Touch Technology: Infrared
Touch Points: 40 on Windows
Operating System: None embedded (no Android)
Use Cases
Ideal Applications
Boardrooms and meeting rooms
Classrooms and training rooms
Digital whiteboarding and brainstorming
Hybrid and remote collaboration
Technical Details
Technical Specifications
Display
Screen Size
75 inch
Display Area
1651 x 929 mm
Resolution
3840 x 2160 (4K)
Aspect Ratio
16:9
Backlight
LED
Brightness
400 cd/m2 (center)
Contrast Ratio
4000:1 (typical)
Response Time
8 ms (typical)
Viewing Angle
178 degrees
Refresh Rate
60 Hz
Display Colours
1.07 billion (8-bit + FRC)
Glass
Anti-glare tempered glass, 3.2 mm, zero bonding
Surface Hardness
8H or higher
Touch and writing
Touch Technology
Infrared
Touch Points
40 on Windows
Writing Tools
Stylus or finger
Touch Accuracy
+/-1 mm
System
Operating System
None embedded (no Android)
Processor
Arm Cortex-A55 x 4
RAM
2 GB
Storage
8 GB
Wireless
Bluetooth 5.2, no Wi-Fi
Audio
Speakers
2 x 10 W average, 15 W maximum, bottom front
Connectivity
Front Ports
1 x USB 2.0 (touch, Type B), 1 x HDMI in, 2 x USB 3.0 (Type A), 1 x USB-C, 1 x microphone in
Rear Ports
2 x HDMI in, 1 x VGA in, 2 x USB 2.0 (signal), 1 x USB 2.0 (embedded), 1 x USB 2.0 (touch), RS232, line out, S/PDIF out, LAN in and out (1000 Mbps), OPS slot
Power and operation
Maximum Power Consumption
620 W
Standby Power
Less than 0.5 W
Physical and mounting
Net Weight
49.9 kg (110 lb)
VESA Mount
800 x 400 mm
Other specifications
Category
Interactive Display, Newline
Why CorporateAV?
Sourced right. Installed right.
Genuine Manufacturer Stock
Every unit sourced through authorized distribution, backed by manufacturer warranty.
Expert AV Integration
Paired correctly with compatible systems and your room's existing AV infrastructure.
Pan-India Delivery & Support
On-site installation and ongoing technical support wherever your project is based.
More Details
Additional Information
Why Buy The TT-7523C From Corporate AV?
- Genuine Newline stock with manufacturer warranty support
- Custom pricing for bulk and multi-room / multi-site rollouts
- Local after-sales support — a real team you can call or WhatsApp, not a call centre
- Expert guidance on product selection and deployment planning
- Professional installation across Bangalore, Hyderabad, Mumbai, Delhi NCR, and the wider India region
Distribution
Corporate AV supplies and installs Newline products across Bangalore, Hyderabad, Mumbai, Delhi NCR, Chennai, Pune, Kolkata, Ahmedabad, and the wider India region.
Frequently Asked Questions
What is the Newline TT-7523C?
The Newline TT-7523C is a 75 inch c series 4K interactive display. Newline's own specification sheet lists the panel, touch, system and connection details below.
Who is the Newline TT-7523C best suited for?
The TT-7523C suits boardrooms and meeting rooms, classrooms and training rooms and digital whiteboarding and brainstorming. Corporate AV can advise whether it is the right fit for your space.
Can Corporate AV supply multiple Newline TT-7523C units for a rollout?
Yes. Corporate AV supplies and integrates the Newline TT-7523C in single units and multi-room rollouts across India, with a site survey, installation, commissioning and support.
How do I get a quote for the Newline TT-7523C in India?
Use the Request a Quote button on this page or contact Corporate AV with your room details and quantity, and a consultant will respond with a quotation for supply and installation.
What are the key specifications of the Newline TT-7523C?
These key specifications are listed for the Newline TT-7523C. Screen Size: 75 inch. Display Area: 1651 x 929 mm. Resolution: 3840 x 2160 (4K). Brightness: 400 cd/m2 (center). Touch Technology: Infrared.
