LG 86TR3D: 86 Inch 4K Interactive Digital Board
Model 86TR3D
Request a Quote
Availability: Out of Stock
- 86 inch 4K Ultra HD IPS panel with 178 degree wide viewing angles
- 20 point Flatfrog InGlass multi touch technology
- LG webOS smart platform with SuperSign IDB software
- Built in Intel OPS expansion slot for a slide in PC module
Product Overview
Overview
The LG 86TR3D is a large scale 4K interactive digital board built for meeting spaces, smart classrooms, and corporate environments.
Specification highlights for the 86TR3D: Screen Size & Panel: 86-inch Commercial-grade LG IPS Panel; Native Resolution: 4K Ultra HD (3840 x 2160) at 16:9 Aspect Ratio; Brightness: 410 cd/m² (Module) / 350 cd/m² (With Protection Glass). Corporate AV supplies and integrates the 86TR3D across India for meeting rooms, classrooms and collaboration spaces, including site survey, installation and commissioning where the project needs it.
Key features
- 86 inch 4K Ultra HD IPS panel with 178 degree wide viewing angles
- 20 point Flatfrog InGlass multi touch technology
- LG webOS smart platform with SuperSign IDB software
- Built in Intel OPS expansion slot for a slide in PC module
- 4mm tempered anti glare, shatter proof safety glass
Why choose the 86TR3D
It puts an 86-inch 4K UHD touch display with 20-point touch in the room, so a meeting or classroom can present, annotate and collaborate on one screen. Corporate AV checks the room, mounting surface, power and network during a site survey, so the 86TR3D is installed and commissioned as part of a complete AV system rather than delivered as a box.
Product Highlights
Key Benefits
86 inch 4K Ultra HD IPS panel with 178 degree wide viewing angles
20 point Flatfrog InGlass multi touch technology
LG webOS smart platform with SuperSign IDB software
Built in Intel OPS expansion slot for a slide in PC module
4mm tempered anti glare, shatter proof safety glass
Use Cases
Ideal Applications
Meeting & Huddle Rooms
Classrooms & Training Rooms
Technical Details
Technical Specifications
Display
Screen Size & Panel
86-inch Commercial-grade LG IPS Panel
Native Resolution
4K Ultra HD (3840 x 2160) at 16:9 Aspect Ratio
Brightness
410 cd/m² (Module) / 350 cd/m² (With Protection Glass)
Viewing Angles
178° Horizontal / 178° Vertical
Contrast Ratio
1,200:1 (Static) | 500,000:1 (Dynamic)
Screen Protection
4T Tempered Anti-Glare, Shatter-Proof Safety Glass
Touch & Interaction
Touch Technology
Flatfrog InGlass™ Multi-Touch Technology
Simultaneous Touch Points
Maximum 20 Points
Touch Precision & Object Size
Accuracy within 2mm | Recognizes objects Ø 3 mm or larger
Processing & Software
Embedded Platform
LG webOS Smart Signage Platform with SuperSign IDB
Connectivity & Expansion
Input Interfaces
3 x HDMI, 1 x DisplayPort, 1 x DVI-D, 1 x RGB (VGA), 1 x Audio In
Output / Control
2 x Touch USB 2.0 Out, 1 x RS232C, 1 x RJ45 (LAN) Network
Physical, Mounting & Compatibility
Physical Dimensions
2,026.9 mm × 1,180.3 mm × 75.6 mm (Without Stand)
Net Hardware Weight
92.7 kg
VESA Mount Interface
600 mm x 400 mm standard patterns
Operation, Power & Environment
Operating Hours / Lifecycle
16 Hours / 7 Days continuous operational duty cycle
General
Feature/Parameter
Technical Specification Details
USB Hub Ecosystem
1 x USB 3.0, 2 x USB 2.0, 1 x OPS USB
Built-in Audio
Integrated Stereo Speaker System (2 x 10W)
Hardware Expansion
Intel Open Pluggable Specification (OPS) Slot (KT-OPSA compatible)
Why CorporateAV?
Sourced right. Installed right.
Genuine Manufacturer Stock
Every unit sourced through authorized distribution, backed by manufacturer warranty.
Expert AV Integration
Paired correctly with compatible systems and your room's existing AV infrastructure.
Pan-India Delivery & Support
On-site installation and ongoing technical support wherever your project is based.
More Details
Additional Information
Why Buy The 86TR3D From Corporate AV?
- Genuine LG stock with manufacturer warranty support
- Custom pricing for bulk and multi-room / multi-site rollouts
- Local after-sales support — a real team you can call or WhatsApp, not a call centre
- Expert guidance on product selection and deployment planning
- Professional installation across Bangalore, Hyderabad, Mumbai, Delhi NCR, and the wider India region
Distribution
Corporate AV supplies and installs LG products across Bangalore, Hyderabad, Mumbai, Delhi NCR, Chennai, Pune, Kolkata, Ahmedabad, and the wider India region.
Frequently Asked Questions
How bright is the LG 86TR3D?
LG lists the brightness of the 86TR3D as: 410 cd/m² (Module) / 350 cd/m² (With Protection Glass).
What resolution does the LG 86TR3D have?
LG lists the resolution of the 86TR3D as: 4K Ultra HD (3840 x 2160) at 16:9 Aspect Ratio.
What panel does the LG 86TR3D use?
LG lists the panel of the 86TR3D as: 86-inch Commercial-grade LG IPS Panel.
What operating hours is the LG 86TR3D designed for?
LG lists the operating hours of the 86TR3D as: 16 Hours / 7 Days continuous operational duty cycle.
What operating system or platform does the LG 86TR3D run?
LG lists the platform of the 86TR3D as: LG webOS Smart Signage Platform with SuperSign IDB.
Does Corporate AV install the LG 86TR3D?
Yes. Corporate AV can supply the 86TR3D only, or deliver it turnkey with site survey, mounting, cabling and commissioning. See our AV installation services for how a project is run.
How do I get a quote for the LG 86TR3D in India?
Use the Request a Quote button on this page or message Corporate AV on WhatsApp. Pricing depends on quantity, delivery location and installation scope, so we prepare a tailored proposal rather than publishing a fixed price.
