Dahua LDH22-SAI200K: 22 Inch Wall-Mounted Digital Signage
Model LDH22-SAI200K
Request a Quote
Availability: Out of Stock
- 22 Inch LCD Screen: Delivers high-definition visuals for maximum impact
- Full HD Resolution: Provides sharp, vibrant image quality for dynamic content
- Wall-mounted Design: Space-saving installation perfect for any environment
- Advanced Content Management: Easily schedule and update digital content remotely
Product Overview
Overview
The Dahua LDH22-SAI200K is a 22 inch wall-mounted digital signage.
Corporate AV supplies, installs and supports the Dahua LDH22-SAI200K across India. Request a quote for supply, installation and commissioning.
Key features
- 22 Inch LCD Screen - Delivers high-definition visuals for maximum impact.
- Full HD Resolution - Provides sharp, vibrant image quality for dynamic content.
- Wall-mounted Design - Space-saving installation perfect for any environment.
- Advanced Content Management - Easily schedule and update digital content remotely.
- Network Connectivity - Supports LAN/Wi-Fi for flexible content delivery and control.
- Robust Security Features - Protects your content and system from unauthorized access.
- Energy Efficient - Designed for low power consumption to reduce operating costs.
Why choose the LDH22-SAI200K
It is a 22 inch wall-mounted signage display for menus, promotions and information screens. Corporate AV adds a site survey, installation and support across India, so the LDH22-SAI200K is specified and installed for your space and not just shipped.
Product Highlights
Key Benefits
22 Inch LCD Screen: Delivers high-definition visuals for maximum impact
Full HD Resolution: Provides sharp, vibrant image quality for dynamic content
Wall-mounted Design: Space-saving installation perfect for any environment
Advanced Content Management: Easily schedule and update digital content remotely
Network Connectivity: Supports LAN/Wi-Fi for flexible content delivery and control
Use Cases
Ideal Applications
Retail stores and showrooms
Corporate lobbies and reception areas
Restaurants, cafes and menu boards
Information and wayfinding screens
Technical Details
Technical Specifications
Display
Panel Dimensions
21.5 inch
Backlight
ELED
LCD Technology
VA
Aspect Ratio
16: 9
Brightness
200 cd/m² (typ.)
Contrast
3000:1(typ.)
Display Colors
8 bit, 16.7M colors
Resolution
1920 (H) × 1080 (V)
Viewing Angle
178° (H); 178° (V)
Response Time
7 ms (typ.)
Surface Treatment
Haze 25%
System
Operating System
Android 8.1
CPU
4 cores A17, 1.6 GHZ
RAM
2 GB
ROM
16 GB
Video Decoding
2-ch H.264 1080p@25 fps; 4-ch H.265 1080p@25 fps; 4-ch H.265 1080p@30 fps; 2-ch H.264 1080p@25 fps; 2-ch H.265 1080p@30 fps; The decoding capacity statistics are based on tests with a single video file.
Audio
Built-in Speaker
2 × 5 W
Media functions
Audio Compression
MPEG-3, WMA, WAV
Video Compression
MPEG-4, H.264/AVC, H.265/HEVC
Video Format
mp4, avi, mov, asf, mkv, wmv
Connectivity
Network Port
1 × RJ–45 10/100/1000 Mbps self-adaptive Ethernet port
Wi-Fi
No (Can be customized)
Bluetooth
NO
Data Transmission Ports
1 × TF card slot, up to 128 GB 2 × USB 2.0 ports (type A)
Video Input
1 × HDMI 1.4 (1080p @60Hz)
Video Output
NO
Audio Port
1 × 3.5 mm jack Mic
IR Receiver
Yes
General
Power Supply
100–240 VAC, 50/60 Hz
Power Consumption
24W (typ.); 40W (max.)
Standby Power Consumpton
≤ 0.5 W
Operating Temperature
0 °C to +40 °C (+32 °F to +104 °F) (avoid direct sunlight)
Storage Temperature
–20 °C to +60 °C (–4 °F to +140 °F)
Operatng Humidity
10%–85% (RH), non-condensing
Storage Humidity
10%–90% (RH), non-condensing
Product Material
Metal casing
Casing Color (Frame/Rear)
Black
Product Dimensions
515.2× 306.7× 49.5mm
Net Weight
5.4Kg
Installation
Wall mount
Display Mode
Landscape/Portrait
Wall Mount VESA
200× 200mm
Accessory
Wall-mount bracket, power cord, legal and regulatory information, user's manual
Certifications
Certifications
CE
Other specifications
Category
Digital Signage, Dahua
Why CorporateAV?
Sourced right. Installed right.
Genuine Manufacturer Stock
Every unit sourced through authorized distribution, backed by manufacturer warranty.
Expert AV Integration
Paired correctly with compatible systems and your room's existing AV infrastructure.
Pan-India Delivery & Support
On-site installation and ongoing technical support wherever your project is based.
More Details
Additional Information
Why Buy The LDH22-SAI200K From Corporate AV?
- Genuine Dahua stock with manufacturer warranty support
- Custom pricing for bulk and multi-room / multi-site rollouts
- Local after-sales support — a real team you can call or WhatsApp, not a call centre
- Expert guidance on product selection and deployment planning
- Professional installation across Bangalore, Hyderabad, Mumbai, Delhi NCR, and the wider India region
Distribution
Corporate AV supplies and installs Dahua products across Bangalore, Hyderabad, Mumbai, Delhi NCR, Chennai, Pune, Kolkata, Ahmedabad, and the wider India region.
Frequently Asked Questions
What is the Dahua LDH22-SAI200K?
The Dahua LDH22-SAI200K is a 22 inch wall-mounted digital signage.
Who is the Dahua LDH22-SAI200K best suited for?
The LDH22-SAI200K suits retail stores and showrooms, corporate lobbies and reception areas, restaurants and cafes and menu boards. Corporate AV can advise whether it is the right fit for your space.
Can Corporate AV supply multiple Dahua LDH22-SAI200K units for a rollout?
Yes. Corporate AV supplies and integrates the Dahua LDH22-SAI200K in single units and multi-room rollouts across India, with a site survey, installation, commissioning and support.
How do I get a quote for the Dahua LDH22-SAI200K in India?
Use the Request a Quote button on this page or contact Corporate AV with your room details and quantity, and a consultant will respond with a quotation for supply and installation.
What are the key specifications of the Dahua LDH22-SAI200K?
These key specifications are listed for the Dahua LDH22-SAI200K. Panel Dimensions: 21.5 inch. Brightness: 200 cd/m² (typ.). Contrast: 3000:1(typ.). Resolution: 1920 (H) × 1080 (V). Operating System: Android 8.1.
