BenQ CP8601K: 86 Inch 4K UHD Interactive Flat Panel (DuoBoard)
Model CP8601K
Request a Quote
Availability: Out of Stock
- 86-inch 4K UHD IPS panel at 350 nits
- Up to 20-point touch (Capacitive touch)
- Android 8 built in
- Operation rating: 18 hours / 7 days
Product Overview
Overview
The BenQ CP8601K is an 86-inch 4K UHD interactive flat panel with up to 20-point touch and Android 8 built in, made for classrooms and training rooms.
Specification highlights for the CP8601K: Screen size: 86 inch; Resolution: UHD 3840 × 2160 pixels; Panel brightness (typical): 350 nits. Corporate AV supplies and integrates the CP8601K across India for meeting rooms, classrooms and collaboration spaces, including site survey, installation and commissioning where the project needs it.
Key features
- 86-inch 4K UHD IPS panel at 350 nits
- Up to 20-point touch (Capacitive touch)
- Android 8 built in
- Operation rating: 18 hours / 7 days
- HDMI in | out: 3 × HDMI 2.0 | 1 × HDMI 2.0
- OPS slot for a slot-in PC: 1
- Built-in speakers: 2 × 10 W
- Microphone: 6 (Max. pickup range 8m)
Why choose the CP8601K
It puts an 86-inch 4K UHD touch display with up to 20-point touch in the room, so a meeting or classroom can present, annotate and collaborate on one screen. Corporate AV checks the room, mounting surface, power and network during a site survey, so the CP8601K is installed and commissioned as part of a complete AV system rather than delivered as a box.
Product Highlights
Key Benefits
86-inch 4K UHD IPS panel at 350 nits
Up to 20-point touch (Capacitive touch)
Android 8 built in
Operation rating: 18 hours / 7 days
HDMI in | out: 3 × HDMI 2.0 | 1 × HDMI 2.0
Use Cases
Ideal Applications
Meeting & Huddle Rooms
Classrooms & Training Rooms
Technical Details
Technical Specifications
Panel
Screen size
86 inch
Panel type
IPS
Active area
1895.0 × 1066.0 mm
Aspect ratio
16:9
Resolution
UHD 3840 × 2160 pixels
Response time
8 ms
Color depth
10-bit
Orientation
Landscape
Operation hours
18 hours / 7 days
Panel brightness (typical)
350 nits
Contrast ratio (typical)
1200:1
Dynamic contrast ratio
30,000:1
Color gamut
68% NTSC
Backlight life (typical)
50,000 hrs
Glass
Germ-resistant technology
Nano-ionic silver
Anti-glare
Yes | NA
Hardness
7H tempered
Touch screen
Touch technology
Capacitive touch
Touch points
20
Touch response time
< 8 ms
System
GPU
Mali-G51MP4
CPU
A73 × 2 + A53 × 2
Memory | Storage
4GB I 32GB
OS
Android 8.0
Connectivity
HDMI (in | out)
3 × HDMI 2.0 | 1 × HDMI 2.0
USB-A
4 × 2.0 + 3 × 3.0
USB-B (for touch)
2 × 2.0
3.5 mm Line in (1)
Mic / PC Audio × 1_test
VGA
1 | 0
3.5 mm Line out
Earphone × 1
OPS slot (for slot-in PC)
1
S/PDIF out
0 | 1 (optical)
Ethernet
10 / 100 / 1000 Mbps (Android), 10 / 100 / 1000 Mbps (OPS) × 1
RS-232
1 | 0
Built-in peripherals
NFC sensor
Yes
Motion sensor
1
Microphone
6 (Max. pickup range 8m)
Speaker
2 × 10 W
Camera
1
Air sensor
TVOC
Subwoofer
1 × 16 W
Power
Power
AC 100-240V 50/60Hz
Standby power consumption
<0.5 W
Typical power consumption
187 W
Physical
Dimensions (W x H x D)
1962.0 × 1167.0 × 85.0 mm (77.2 × 45.9 × 3.3 inch)
Shipping dimensions (W x H x D)
2146 × 1326 × 280 mm (84.5 × 52.2 × 11.0 inch)
Weight (product I shipping)
71.5 kg | 97.9 kg (157.6 lbs | 215.8 lbs)
Mount (screws)
VESA 800 × 600 mm (4 × M8 × 25L)
Environment
Operating temperature
0°C ~ 40°C | 32°F ~ 104°F
Storage temperature
-20°C ~ 60°C | -4°F ~ 140°F
Storage humidity
10% ~ 90% RH non-condensing
Operating humidity
10% ~ 90% RH non-condensing
Software
Whiteboarding
EZWrite 5.0
Wireless screen sharing
InstaShare 2
Device management
DMS
Account management
AMS
Flicker Free
Yes
Quick access tool
Floating Tool
Broadcast system
X-Sign Broadcast
Low Blue Light
Yes
Accessories
Cables
1 × VGA(5 m | 16.4 ft), 1 × HDMI (1.5 m | 4.9 ft), 1 × USB (3 m | 9.8 ft)
Wall mount
1
Pen
2
Remote control
1
In The Box
What's Included
Cables: 1 × VGA(5 m | 16.4 ft), 1 × HDMI (1.5 m | 4.9 ft), 1 × USB (3 m | 9.8 ft)
Wall mount
Pen × 2
Remote control
Why CorporateAV?
Sourced right. Installed right.
Genuine Manufacturer Stock
Every unit sourced through authorized distribution, backed by manufacturer warranty.
Expert AV Integration
Paired correctly with compatible systems and your room's existing AV infrastructure.
Pan-India Delivery & Support
On-site installation and ongoing technical support wherever your project is based.
More Details
Additional Information
Why Buy The CP8601K From Corporate AV?
- Genuine BenQ stock with manufacturer warranty support
- Custom pricing for bulk and multi-room / multi-site rollouts
- Local after-sales support — a real team you can call or WhatsApp, not a call centre
- Expert guidance on product selection and deployment planning
- Professional installation across Bangalore, Hyderabad, Mumbai, Delhi NCR, and the wider India region
Distribution
Corporate AV supplies and installs BenQ products across Bangalore, Hyderabad, Mumbai, Delhi NCR, Chennai, Pune, Kolkata, Ahmedabad, and the wider India region.
Frequently Asked Questions
How bright is the BenQ CP8601K?
BenQ lists the brightness of the CP8601K as: 350 nits.
What resolution does the BenQ CP8601K have?
BenQ lists the resolution of the CP8601K as: UHD 3840 × 2160 pixels.
What panel does the BenQ CP8601K use?
BenQ lists the panel of the CP8601K as: IPS.
What operating hours is the BenQ CP8601K designed for?
BenQ lists the operation hours of the CP8601K as: 18 hours / 7 days.
What operating system does the BenQ CP8601K run?
BenQ lists the operating system of the CP8601K as: Android 8.0.
Does Corporate AV install the BenQ CP8601K?
Yes. Corporate AV can supply the CP8601K only, or deliver it turnkey with site survey, mounting, cabling and commissioning. See our AV installation services for how a project is run.
How do I get a quote for the BenQ CP8601K in India?
Use the Request a Quote button on this page or message Corporate AV on WhatsApp. Pricing depends on quantity, delivery location and installation scope, so we prepare a tailored proposal rather than publishing a fixed price.
