TOA P-2240: Power Amplifier
Model P-2240
Request a Quote
Availability: Out of Stock
- 240 W output power
- 100 V line input allows connection to speaker output of A-2000 series amplifiers
- Remote power control allows operation independently from A-2000 series amplifiers
- Emergency bypass of master volume
Product Overview
Overview
The TOA P-2240 is power amplifier featuring high cost performance suited for paging applications in schools, churches, offices and retail stores.
Corporate AV supplies, installs and supports TOA audio systems across India. Request a quote for the TOA P-2240 with supply, installation and commissioning.
Key features
- 240 W output power
- 100 V line input allows connection to speaker output of A-2000 series amplifiers
- Remote power control allows operation independently from A-2000 series amplifiers
- Emergency bypass of master volume
- 2U high
Typical applications
- Multi-zone public address and background music
- Auditoriums, halls and public venues
- Constant-voltage and low-impedance speaker lines
Why choose the P-2240
it is a power amplifier from TOA, supplied with Corporate AV's site survey, installation and support across India, so the P-2240 is specified for your project and not just shipped.
Product Highlights
Key Benefits
240 W output power
100 V line input allows connection to speaker output of A-2000 series amplifiers
Remote power control allows operation independently from A-2000 series amplifiers
Emergency bypass of master volume
2U high
Use Cases
Ideal Applications
Multi-zone public address and background music
Auditoriums, halls and public venues
Constant-voltage and low-impedance speaker lines
Technical Details
Technical Specifications
Specifications
Power Source
220 - 240 V AC, or 24 - 30 V DC
Power Consumption
238 W (EN60065), 520 W (AC operation at rated output), 15 A (DC operation at rated output)
Rated Output
240 W
Output
Loop out: 0 dB*, 10 kΩ, balanced, screw terminal Speaker out: Balanced (floating) High impedance: 42 Ω (100 V), 21 Ω (70 V) Low impedance: 4 Ω (31 V)
Frequency Response
50 - 20,000 Hz (±3 dB)
Distortion
Under 1% at 1 kHz, 1/3 rated power
Signal to Noise Ratio
Over 60 dB
Tone Control
Bass: ±10 dB at 100 Hz Treble: ±10 dB at 10 kHz
Ventilation
Fan cooling
Dimensions & finish
Finish
Panel: ABS resin, black Case: Steel plate, black
Dimensions
420 (W) x 100.9 (H) x 351.3 (D) mm (16.54 x 3.97" x 13.83")"
Weight
13.2 kg (29.1 lb)
Why CorporateAV?
Sourced right. Installed right.
Genuine Manufacturer Stock
Every unit sourced through authorized distribution, backed by manufacturer warranty.
Expert AV Integration
Paired correctly with compatible systems and your room's existing AV infrastructure.
Pan-India Delivery & Support
On-site installation and ongoing technical support wherever your project is based.
More Details
Additional Information
Why Buy The P-2240 From Corporate AV?
- Genuine TOA stock with manufacturer warranty support
- Custom pricing for bulk and multi-room / multi-site rollouts
- Local after-sales support — a real team you can call or WhatsApp, not a call centre
- Expert guidance on product selection and deployment planning
- Professional installation across Bangalore, Hyderabad, Mumbai, Delhi NCR, and the wider India region
Distribution
Corporate AV supplies and installs TOA products across Bangalore, Hyderabad, Mumbai, Delhi NCR, Chennai, Pune, Kolkata, Ahmedabad, and the wider India region.
Frequently Asked Questions
What is the TOA P-2240?
The TOA P-2240 is power amplifier featuring high cost performance suited for paging applications in schools, churches, offices and retail stores.
What are the main specifications of the TOA P-2240?
TOA lists these figures for the P-2240: Rated Output: 240 W; Power Source: 220 - 240 V AC, or 24 - 30 V DC; Frequency Response: 50 - 20,000 Hz (±3 dB); Distortion: Under 1% at 1 kHz, 1/3 rated power. The full specification table is on this page.
What are the key features of the TOA P-2240?
TOA highlights: 240 W output power; 100 V line input allows connection to speaker output of A-2000 series amplifiers; remote power control allows operation independently from A-2000 series amplifiers; emergency bypass of master volume.
Where is the TOA P-2240 used?
It suits: multi-zone public address and background music; auditoriums, halls and public venues; constant-voltage and low-impedance speaker lines. Corporate AV can advise whether it fits your project.
Which TOA series is the P-2240 part of?
TOA lists the P-2240 in its A-2000 Series Mixer Amplifier range.
Can Corporate AV supply and install the TOA P-2240 in India?
Yes. Corporate AV supplies, installs and supports TOA audio systems across India, with a site survey, commissioning and after-sales support.
How do I get a quote for the TOA P-2240?
Use the Request a Quote button on this page or contact Corporate AV with your project details and quantity, and a consultant will respond with a quotation for supply and installation.
