TOA MX-9200: Mixer Pre-Amplifier
Model MX-9200
Request a Quote
Availability: Out of Stock
- Better sound quality
- Versatile installation application
- Suitable for large functions and small-scale religious worship
Product Overview
Overview
The TOA MX-9200 is a wireless mixer pre-amplifier ideal for function rooms, training rooms and even small-scale houses of worship. It's equipped with up to 9 inputs of which 4 inputs comes with phantom power.
Corporate AV supplies, installs and supports TOA audio systems across India. Request a quote for the TOA MX-9200 with supply, installation and commissioning.
Key features
- Better sound quality
- Versatile installation application
- Suitable for large functions and small-scale religious worship
Typical applications
- Meeting and conference rooms
- Paging and background music systems
- Small venues and hospitality spaces
Why choose the MX-9200
it is a mixer pre-amplifier from TOA, supplied with Corporate AV's site survey, installation and support across India, so the MX-9200 is specified for your project and not just shipped.
Product Highlights
Key Benefits
Better sound quality
Versatile installation application
Suitable for large functions and small-scale religious worship
Use Cases
Ideal Applications
Meeting and conference rooms
Paging and background music systems
Small venues and hospitality spaces
Technical Details
Technical Specifications
Specifications
Power Source
220 - 240 V AC, 14 W
Frequency Response
30 Hz - 20 kHz, ± 3dB
Distortion
Under 1 % at 1 kHz, rated power
Input
Input CH 1 with Phantom option 19 V DC: - CHIME MIC: Balanced, Selectable sensitivity -55 dB (1.8 mV)/ -30 dB (30 mV), 2.2 kΩ, rated 1 kHz, RJ45 connector - MIC: Balanced, Selectable sensitivity -55 dB (1.8 mV)/ -30 dB (30 mV), 2.2 kΩ, rated 1 kHz, Phone jack connector Input CH 2-4 with Phantom option 19 V DC: - Balanced, Sensitivity -55 dB (1.8 mV), 2.2 kΩ, rated 1 kHz, Phone jack connector Selectable Input CH 5 with options: - MIC: Balanced, Sensitivity -55 dB (1.8 mV), 2.2 kΩ, rated 1 kHz, Phone jack connector - AUX: Unbalanced, Sensitivity 0 dB (1.8 mV), 10 kΩ, rated 1 kHz, RCA jack connector Selectable Sensitivity Input CH 6-8, Removable terminal 3 pins with sensitivity options: - LINE: Balanced, Sensitivity 0 dB, 2.2 kΩ, rated 1 kHz - MIC: Balanced, Sensitivity -55 dB (1.8 mV), 2.2 kΩ, rated 1 kHz Selectable Sensitivity Input CH 9, Removable terminal 3 pins with sensitivity options: - MIC: Balanced, Sensitivity -55 dB (1.8 mV), 2.2 kΩ, rated 1 kHz - STREAMING: Unbalanced, Sensitivity 0 dB, 10 kΩ, rated 1 kHz
Output
Audio OUT A & B, Balanced, Removable terminal 3 pins Optional output level: 0 dB / -10 dB (300 mV) / -20 dB (100 mV), 600 Ω, rated 1 kHz
Control Output
9 Shortcut switch IN, 2 Shortcut switch OUT, 1 Shortcut switch VOLUME, 1 Shortcut switch TONE CONTROL, 1 Shortcut switch INPUT SELECTION, 1 Navigation switch (Right, Left, Push)
Connection
Bluetooth 4.2, USB Type B (PC Setting/Update Firmware)
Tone Controller
Bass ± 13 dB at 100 Hz, Middle ± 13 dB at 1 kHz, Treble ± 13 dB at 10 kHz
Operating Temperature
0 °C to +40 °C
Operating Humidity
Under 90 % RH (no condensation)
Included Accessories
6P connector x 2, 3P connector x 2
Dimensions & finish
Finish
Front Panel: Aluminium Hair Line, Paint, Black Case: Steel Plate, Paint, Black
Dimensions
420 (W) × 59 (H) × 339.7 (D) mm
Weight
3.3 kg
Why CorporateAV?
Sourced right. Installed right.
Genuine Manufacturer Stock
Every unit sourced through authorized distribution, backed by manufacturer warranty.
Expert AV Integration
Paired correctly with compatible systems and your room's existing AV infrastructure.
Pan-India Delivery & Support
On-site installation and ongoing technical support wherever your project is based.
More Details
Additional Information
Why Buy The MX-9200 From Corporate AV?
- Genuine TOA stock with manufacturer warranty support
- Custom pricing for bulk and multi-room / multi-site rollouts
- Local after-sales support — a real team you can call or WhatsApp, not a call centre
- Expert guidance on product selection and deployment planning
- Professional installation across Bangalore, Hyderabad, Mumbai, Delhi NCR, and the wider India region
Distribution
Corporate AV supplies and installs TOA products across Bangalore, Hyderabad, Mumbai, Delhi NCR, Chennai, Pune, Kolkata, Ahmedabad, and the wider India region.
Frequently Asked Questions
What is the TOA MX-9200?
The TOA MX-9200 is a wireless mixer pre-amplifier ideal for function rooms, training rooms and even small-scale houses of worship. It's equipped with up to 9 inputs of which 4 inputs comes with phantom power.
What are the main specifications of the TOA MX-9200?
TOA lists these figures for the MX-9200: Power Source: 220 - 240 V AC, 14 W; Frequency Response: 30 Hz - 20 kHz, ± 3dB; Distortion: Under 1 % at 1 kHz, rated power; Input: Input CH 1 with Phantom option 19 V DC: - CHIME MIC: Balanced, Selectable sensitivity -55 dB (1.8 mV)/ -30 dB (30 mV), 2.2 kΩ, rated 1 kHz, RJ45 connector - MIC: Balanced, Selectable sensitivity -55 dB (1.8 mV)/ -30 dB (30 mV), 2.2 kΩ, rated 1 kHz, Phone jack connector Input CH 2-4 with Phantom option 19 V DC: - Balanced, Sensitivity -55 dB (1.8 mV), 2.2 kΩ, rated 1 kHz, Phone jack connector Selectable Input CH 5 with options: - MIC: Balanced, Sensitivity -55 dB (1.8 mV), 2.2 kΩ, rated 1 kHz, Phone jack connector - AUX: Unbalanced, Sensitivity 0 dB (1.8 mV), 10 kΩ, rated 1 kHz, RCA jack connector Selectable Sensitivity Input CH 6-8, Removable terminal 3 pins with sensitivity options: - LINE: Balanced, Sensitivity 0 dB, 2.2 kΩ, rated 1 kHz - MIC: Balanced, Sensitivity -55 dB (1.8 mV), 2.2 kΩ, rated 1 kHz Selectable Sensitivity Input CH 9, Removable terminal 3 pins with sensitivity options: - MIC: Balanced, Sensitivity -55 dB (1.8 mV), 2.2 kΩ, rated 1 kHz - STREAMING: Unbalanced, Sensitivity 0 dB, 10 kΩ, rated 1 kHz. The full specification table is on this page.
What are the key features of the TOA MX-9200?
TOA highlights: better sound quality; versatile installation application; suitable for large functions and small-scale religious worship.
Where is the TOA MX-9200 used?
It suits: meeting and conference rooms; paging and background music systems; small venues and hospitality spaces. Corporate AV can advise whether it fits your project.
Which TOA series is the MX-9200 part of?
TOA lists the MX-9200 in its MX-9200 range.
Can Corporate AV supply and install the TOA MX-9200 in India?
Yes. Corporate AV supplies, installs and supports TOA audio systems across India, with a site survey, commissioning and after-sales support.
How do I get a quote for the TOA MX-9200?
Use the Request a Quote button on this page or contact Corporate AV with your project details and quantity, and a consultant will respond with a quotation for supply and installation.
