TOA A-5012: Digital Mixer Amplifier
Model A-5012
Request a Quote
Availability: Out of Stock
- 60 W or 120 W
- 2 x mic/line inputs with mute function
- 5-band Parametric Equalizer for each input and output (DSP)
- Remote Master Volume Control
Product Overview
Overview
The TOA A-5012 is a half-rack 1-unit size 120 W desktop mixer power amplifier. Inputs 1 and 2 can be set for either MIC or LINE sound sources, and its output is compatible with both high-impedance (100 V and 70 V lines) and low-impedance (4 ohms) speaker connections.
Corporate AV supplies, installs and supports TOA audio systems across India. Request a quote for the TOA A-5012 with supply, installation and commissioning.
Key features
- 60 W or 120 W
- 2 x mic/line inputs with mute function
- 5-band Parametric Equalizer for each input and output (DSP)
- Remote Master Volume Control
- Mute (Mic 1 priority: Manual mute)
- Compressor for both input 1 and 2
Typical applications
- Paging and background music in offices, shops and factories
- Schools, houses of worship and public buildings
- Constant-voltage (100 V) speaker distribution
Why choose the A-5012
it is a digital mixer amplifier from TOA, supplied with Corporate AV's site survey, installation and support across India, so the A-5012 is specified for your project and not just shipped.
Product Highlights
Key Benefits
60 W or 120 W
2 x mic/line inputs with mute function
5-band Parametric Equalizer for each input and output (DSP)
Remote Master Volume Control
Mute (Mic 1 priority: Manual mute)
Use Cases
Ideal Applications
Paging and background music in offices, shops and factories
Schools, houses of worship and public buildings
Constant-voltage (100 V) speaker distribution
Technical Details
Technical Specifications
Specifications
Power Source
100-240 V AC, 50/60 Hz
Rated Output
120 W
Power/Current Consumption
207 W (rated output), 39 W (based on cULus standards) Max. 3 A
Frequency Response
50 Hz - 20 kHz (1/8 rated output)
Distortion
1 % or less (1 kHz, rated output)
Input
INPUT 1, 2: MIC -60 dB(*1) LINE -20 dB(*1) MIC/LINE selectable 2.2 kΩ, electronically-balanced, removable terminal block (5 pins) INPUT 3, 4: LINE -20 dB(*1), 10 kΩ, unbalanced, RCA pin jack
Output
SPEAKER: 4 Ω, 70 V (42 Ω), 100 V (83 Ω), removable terminal block (5 pins)
Signal to Noise Ratio
MIC 1, 2: 50 dB or more LINE 1 - 4: 70 dB or more (A-weighted)
Function
Parametric equalizer: 5 points settable on each input and output 20 Hz - 20 kHz ±15 dB Q: 0.267 - 69.249 Compressor: ON/OFF settable on Inputs 1 and 2 (OFF by default) Threshold, Ratio, Attack time, Release time, and Gain are settable independently on each input.
Control
Mute control, Remote master volume control, Power ON/OFF switch, Ground lift
LED Indicator
Power indicator, Signal indicator, Peak indicator, Protect indicator
Network I/F
100BASE-TX
Operating Temperature
0 ℃ to +40 ℃ (32 ℉ to 104 ℉)
Operating Humidity
35 % to 80 %RH (no condensation)
Included Accessories
Large type removable terminal plug (5 pins) x 1, Small type removable terminal plug (5 pins) x 2, Plain washer (*2) x 6, Bracket mounting screw (M3 x 10) (*2) x 6, Power supply cord (2 m (6.56 ft) x 1
Optional Accessories
Half width blank panel: MB-15B-BK (for rack mounting one A-5012 unit) (*2) Rack joint bracket: MB-15B-J (for rack mounting two A-5012 units) (*2) Rack runner: YA-706
Dimensions & finish
Finish
Panel: PS resin, black Case: Surface-treated steel plate, black, paint
Dimensions
210 (W) x 52.5 (H) x 375 (D) mm (8.27 x 2.07" x 14.76")
Weight
3.9 kg (8.6 lb)
Why CorporateAV?
Sourced right. Installed right.
Genuine Manufacturer Stock
Every unit sourced through authorized distribution, backed by manufacturer warranty.
Expert AV Integration
Paired correctly with compatible systems and your room's existing AV infrastructure.
Pan-India Delivery & Support
On-site installation and ongoing technical support wherever your project is based.
More Details
Additional Information
Why Buy The A-5012 From Corporate AV?
- Genuine TOA stock with manufacturer warranty support
- Custom pricing for bulk and multi-room / multi-site rollouts
- Local after-sales support — a real team you can call or WhatsApp, not a call centre
- Expert guidance on product selection and deployment planning
- Professional installation across Bangalore, Hyderabad, Mumbai, Delhi NCR, and the wider India region
Distribution
Corporate AV supplies and installs TOA products across Bangalore, Hyderabad, Mumbai, Delhi NCR, Chennai, Pune, Kolkata, Ahmedabad, and the wider India region.
Frequently Asked Questions
What is the TOA A-5012?
The TOA A-5012 is a half-rack 1-unit size 120 W desktop mixer power amplifier. Inputs 1 and 2 can be set for either MIC or LINE sound sources, and its output is compatible with both high-impedance (100 V and 70 V lines) and low-impedance (4 ohms) speaker connections.
What are the main specifications of the TOA A-5012?
TOA lists these figures for the A-5012: Rated Output: 120 W; Power Source: 100-240 V AC, 50/60 Hz; Frequency Response: 50 Hz - 20 kHz (1/8 rated output); Distortion: 1 % or less (1 kHz, rated output). The full specification table is on this page.
What are the key features of the TOA A-5012?
TOA highlights: 60 W or 120 W; 2 x mic/line inputs with mute function; 5-band Parametric Equalizer for each input and output (DSP); remote Master Volume Control.
Where is the TOA A-5012 used?
It suits: paging and background music in offices, shops and factories; schools, houses of worship and public buildings; constant-voltage (100 V) speaker distribution. Corporate AV can advise whether it fits your project.
Which TOA series is the A-5012 part of?
TOA lists the A-5012 in its A-5000 Series Digital Mixer Amplifier range.
Can Corporate AV supply and install the TOA A-5012 in India?
Yes. Corporate AV supplies, installs and supports TOA audio systems across India, with a site survey, commissioning and after-sales support.
How do I get a quote for the TOA A-5012?
Use the Request a Quote button on this page or contact Corporate AV with your project details and quantity, and a consultant will respond with a quotation for supply and installation.
