Bose ArenaMatch AMWG2060: AM20 60 Degree Horizontal Waveguide

Model ArenaMatch AMWG2060

Request a Quote
Availability: Out of Stock
Request a Quote Chat on WhatsApp
  • Authorized Bose Reseller
  • Manufacturer Warranty
  • Pan-India Delivery
  • Expert Project Support
  • Swaps onto the AM20 module to change horizontal dispersion to 60 degrees while keeping the module's 20 degree vertical pattern
  • Calibrated specifically for the AM20 DeltaQ array loudspeaker, not interchangeable with AM10 or AM40 waveguides
  • Lets integrators build lighter, faster to install arrays by changing coverage without swapping the whole loudspeaker
  • IP55 rated for direct exposure outdoor use alongside the AM20 module it pairs with
Installed Audio Solutions for Business Part of our complete AV solutions Explore Solutions
View full details
Product Overview

Overview

The Bose ArenaMatch AMWG2060 is a Bose Professional accessory waveguide that sets the horizontal coverage of an ArenaMatch AM20 DeltaQ array loudspeaker module to 60 degrees for outdoor and installed sound projects.

Corporate AV supplies the ArenaMatch AMWG2060 across India for Bose ArenaMatch and ShowMatch arrays, alongside the Bose loudspeakers and AV systems it is used with.

Key features

  • Swaps onto the AM20 module to change horizontal dispersion to 60 degrees while keeping the module's 20 degree vertical pattern
  • Calibrated specifically for the AM20 DeltaQ array loudspeaker, not interchangeable with AM10 or AM40 waveguides
  • Lets integrators build lighter, faster to install arrays by changing coverage without swapping the whole loudspeaker
  • IP55 rated for direct exposure outdoor use alongside the AM20 module it pairs with
Why choose the ArenaMatch AMWG2060
It changes the coverage pattern of a compatible Bose array module, so the system can be tuned to the audience area. Corporate AV supplies the ArenaMatch AMWG2060 with the Bose systems it is used alongside, so it is specified as part of a complete setup.
Product Highlights

Key Benefits

Swaps onto the AM20 module to change horizontal dispersion to 60 degrees while keeping the module's 20 degree vertical pattern

Calibrated specifically for the AM20 DeltaQ array loudspeaker, not interchangeable with AM10 or AM40 waveguides

Lets integrators build lighter, faster to install arrays by changing coverage without swapping the whole loudspeaker

IP55 rated for direct exposure outdoor use alongside the AM20 module it pairs with

Use Cases

Ideal Applications

Auditoriums & Large Venues

Outdoor & Semi-Outdoor Sites

Retail Stores & Malls

Offices & Corporate Spaces

Technical Details

Technical Specifications

Acoustic performance
Coverage Pattern (AM20/60) 60 degrees horizontal x 20 degrees vertical
Sensitivity (1W/1m) 94 dB LF / 106 dB HF / 99 dB passive
Maximum SPL 122 dB LF / 128 dB HF / 128 dB passive
Power Handling Up to 750W RMS bi-amplified
Frequency Response 55 Hz to 18 kHz
Impedance 8 ohm passive, 8 ohm plus 8 ohm bi-amp
Mounting and compatibility
Compatible Module Bose ArenaMatch AM20 DeltaQ array loudspeaker
Environment and compliance
Environmental Rating IP55
General
AM20 Driver Complement Six Bose EMB2S compression drivers and one 14 inch neodymium woofer
Part Number 808667-3610

Related Solutions

Why CorporateAV?

Sourced right. Installed right.

Genuine Manufacturer Stock
Every unit sourced through authorized distribution, backed by manufacturer warranty.
Expert AV Integration
Paired correctly with compatible systems and your room's existing AV infrastructure.
Pan-India Delivery & Support
On-site installation and ongoing technical support wherever your project is based.
More Details

Additional Information

Why Buy The ArenaMatch AMWG2060 From Corporate AV?
  • Genuine Bose stock with manufacturer warranty support
  • Custom pricing for bulk and multi-room / multi-site rollouts
  • Local after-sales support — a real team you can call or WhatsApp, not a call centre
  • Expert guidance on product selection and deployment planning
  • Professional installation across Bangalore, Hyderabad, Mumbai, Delhi NCR, and the wider India region
Contact us: +91 99452 30186, WhatsApp us or email avsupport@corporateav.in.
Distribution

Corporate AV supplies and installs Bose products across Bangalore, Hyderabad, Mumbai, Delhi NCR, Chennai, Pune, Kolkata, Ahmedabad, and the wider India region.

Frequently Asked Questions

What frequency range does the Bose ArenaMatch AMWG2060 cover?
Bose lists the frequency range of the ArenaMatch AMWG2060 as: 55 Hz to 18 kHz.
What power does the Bose ArenaMatch AMWG2060 handle?
Bose lists the power of the ArenaMatch AMWG2060 as: Up to 750W RMS bi-amplified.
How loud does the Bose ArenaMatch AMWG2060 get?
Bose lists the maximum output of the ArenaMatch AMWG2060 as: 122 dB LF / 128 dB HF / 128 dB passive.
What coverage does the Bose ArenaMatch AMWG2060 offer?
Bose lists the coverage of the ArenaMatch AMWG2060 as: 60 degrees horizontal x 20 degrees vertical.
What impedance does the Bose ArenaMatch AMWG2060 use?
Bose lists the impedance of the ArenaMatch AMWG2060 as: 8 ohm passive, 8 ohm plus 8 ohm bi-amp.
Can the Bose ArenaMatch AMWG2060 be used outdoors?
Bose lists the environmental rating of the ArenaMatch AMWG2060 as: IP55.
How do I get a quote for the Bose ArenaMatch AMWG2060 in India?
Use the Request a Quote button on this page or message Corporate AV on WhatsApp. Pricing depends on quantity, delivery location and installation scope, so we prepare a tailored proposal rather than publishing a fixed price.
