Avocor AVE-9200: 92 Inch 21:9 5K Ultra-Wide Interactive Display
Model AVE-9200
Request a Quote
Availability: Out of Stock
- 92-inch 21:9 ultra-wide panel at 5120 x 2160 and 60 Hz
- Up to 50-point IR touch plus one stylus
- 450 cd/m², 4000:1 contrast, 178 degree viewing angles
- Zero-parallax, zero-bond, anti-glare and anti-fingerprint glass
Product Overview
Overview
The Avocor AVE-9200 is a 92-inch 21:9 5K ultra-wide interactive display. Its 92-inch 21:9 panel delivers 5120 x 2160 resolution on one wide canvas that replaces a dual-monitor setup, with up to 50 IR touch points plus one stylus. The display is rated for 16 hours a day, 7 days a week, uses toughened glass with a 30,000-hour backlight life and is optimised for Microsoft Teams and Zoom (software is sold separately). Product dimensions are 2203 x 92 x 1000 mm (86.7 x 3.6 x 39.4") and the net weight is 67.6 kg (149 lbs), with a 800 x 600 mm VESA wall-mount pattern.
Corporate AV supplies, installs and supports Avocor solutions across India. Request a quote for the Avocor AVE-9200 with supply, installation and commissioning.
Key features
- 92-inch 21:9 ultra-wide panel at 5120 x 2160 and 60 Hz
- Up to 50-point IR touch plus one stylus
- 450 cd/m², 4000:1 contrast, 178 degree viewing angles
- Zero-parallax, zero-bond, anti-glare and anti-fingerprint glass
- Built-in Android 13 system (RK3588, 8 GB / 64 GB)
- 2 x 20 W speakers plus a 20 W subwoofer
- Front Type-C (15 W PD) and USB ports, rear Type-C (100 W), DisplayPort 1.4 and 3 x HDMI 2.0
- OPS slot for an optional slot-in PC
Typical applications
- Boardrooms and large collaboration rooms
- Teams and Zoom meeting spaces
- Design reviews and brainstorming sessions
Why choose the AVE-9200
it is a 92-inch 21:9 5K ultra-wide interactive display from Avocor, supplied with Corporate AV's site survey, installation and support across India, so the AVE-9200 is specified for your project and not just shipped.
Product Highlights
Key Benefits
92-inch 21:9 ultra-wide panel at 5120 x 2160 and 60 Hz
Up to 50-point IR touch plus one stylus
450 cd/m², 4000:1 contrast, 178 degree viewing angles
Zero-parallax, zero-bond, anti-glare and anti-fingerprint glass
Built-in Android 13 system (RK3588, 8 GB / 64 GB)
Use Cases
Ideal Applications
Boardrooms and large collaboration rooms
Teams and Zoom meeting spaces
Design reviews and brainstorming sessions
Technical Details
Technical Specifications
Display
Screen Size
92"
Backlight
Direct-lit LED
Aspect Ratio
21:9
Resolution
5120 x 2160 @ 60 Hz
Response Time
6.5 ms (Typ)
Brightness
450 cd/m²
Contrast Ratio
4000:1
Viewing Angle
178° / 178°
Supported Colors
1.07B (8 bit + FRC)
Rated Operation
7 days x 16 hours
Display Orientation
Landscape
Touch System
Interface
2 x USB-B 2.0, 1 x Type-C
Touch
Up to 50 point IR + 1 stylus
Glass
Zero parallax, zero-bond, anti-glare, anti-fingerprint glass
Supported Operating System
Windows 7 / 8 / 10 / 11 WindowsXP / Linux / Mac / Android
CPU
CPU
Rockchip RK3588 A76 x 4 + A55 x 4
GPU
Mali-G610 MP4
RAM / ROM
8 GB / 64 GB
Android Version
Android 13
Connectivity
Front / Guest Inputs
1 x Type-C (15 W PD), 2 x USB-A 3.0
Top Inputs
2 x USB-A 3.0
Side IO
1 x Type-C (100 W), 1 x DP 1.4, 3 x HDMI 2.0, HDCP 2.3, 3 x USB-B 2.0, USB-A 3.0, 1 x HDMI 2.0 out
Audio
1 x 3.5 mm Aux + 1 x Optical (SPDIF)
Control
1 x RS-232, 2 x RJ45
OPS Slot
Yes
WiFi
Yes
Audio
Built-in Speakers
2 x 20 W + 20 W sub
Display & Remote Functions
Auto-Source Detection
Yes
Image Settings
Yes, UiQ
Physical Specifications
Product Dimensions (L x W x H)
2203 x 92 x 1000 mm (86.7 x 3.6 x 39.4")
Bezel Dimensions
Top: 29 mm, Sides: 18 mm, Bottom 39 mm (Top: 1.14", Sides: 0.7", Bottom: 1.5")
Shipping Dimensions (L x W x H)
2360 x 225 x 1140 mm (92.9 x 8.8 x 44.8")
Weight (Net)
67.6 kg (149 lbs)
Weight (Gross)
88.5 kg (195 lbs)
Wall Mount (VESA)
800 x 600 mm
Handles
2
Power
Power Supply
AC IN 100 - 240V~50 / 60 Hz
AC Power Out
AC Out 100 - 240V~50 / 60 Hz
Max Power Consumption
250 W (w/o OPS)
Standby
≤0.5 W
Environmental
Operating Temperature
0°C ~ 40°C
Storage Temperature
-20°C ~ 60°C
Humidity
10% - 90%
In The Box
What's Included
1 x Remote control & batteries
2 x 3mm fine-tip passive touch styluses
AC power cords
1 x USB-B 3.0 cable (3 m)
1 x HDMI cable (3 m)
1 x Type-C cable (1.8 m)
Wall Mount
WiFi module included
Why CorporateAV?
Sourced right. Installed right.
Genuine Manufacturer Stock
Every unit sourced through authorized distribution, backed by manufacturer warranty.
Expert AV Integration
Paired correctly with compatible systems and your room's existing AV infrastructure.
Pan-India Delivery & Support
On-site installation and ongoing technical support wherever your project is based.
More Details
Additional Information
Why Buy The AVE-9200 From Corporate AV?
- Genuine Avocor stock with manufacturer warranty support
- Custom pricing for bulk and multi-room / multi-site rollouts
- Local after-sales support — a real team you can call or WhatsApp, not a call centre
- Expert guidance on product selection and deployment planning
- Professional installation across Bangalore, Hyderabad, Mumbai, Delhi NCR, and the wider India region
Distribution
Corporate AV supplies and installs Avocor products across Bangalore, Hyderabad, Mumbai, Delhi NCR, Chennai, Pune, Kolkata, Ahmedabad, and the wider India region.
Frequently Asked Questions
What is the Avocor AVE-9200?
The Avocor AVE-9200 is a 92-inch 21:9 5K ultra-wide interactive display. Its 92-inch 21:9 panel delivers 5120 x 2160 resolution on one wide canvas that replaces a dual-monitor setup, with up to 50 IR touch points plus one stylus.
What are the main specifications of the Avocor AVE-9200?
Avocor lists these figures for the AVE-9200: resolution: 5120 x 2160 @ 60 Hz; brightness: 450 cd/m²; touch: Up to 50 point IR + 1 stylus; contrast ratio: 4000:1; CPU: Rockchip RK3588 A76 x 4 + A55 x 4. The full specification table is on this page.
What connections does the Avocor AVE-9200 have?
Avocor lists these inputs and ports. Front / Guest Inputs: 1 x Type-C (15 W PD), 2 x USB-A 3.0. Top Inputs: 2 x USB-A 3.0. Side IO: 1 x Type-C (100 W), 1 x DP 1.4, 3 x HDMI 2.0, HDCP 2.3, 3 x USB-B 2.0, USB-A 3.0, 1 x HDMI 2.0 out.
What are the dimensions and weight of the Avocor AVE-9200?
Product dimensions are 2203 x 92 x 1000 mm (86.7 x 3.6 x 39.4") and the net weight is 67.6 kg (149 lbs), with a 800 x 600 mm VESA wall-mount pattern.
Why choose a 21:9 display like the Avocor AVE-9200?
Avocor positions the 21:9 aspect ratio as an alternative to dual-monitor setups: it widens the interactive workspace and lets several application windows sit side by side.
Where is the Avocor AVE-9200 used?
It suits: boardrooms and large collaboration rooms; Teams and Zoom meeting spaces; design reviews and brainstorming sessions. Corporate AV can advise whether it fits your project.
Can Corporate AV supply and install the Avocor AVE-9200 in India, and how do I get a quote?
Yes. Corporate AV supplies, installs and supports Avocor solutions across India, with a site survey, commissioning and after-sales support. Use the Request a Quote button on this page or contact Corporate AV with your project details and quantity.
