AVer MD120UI: Medical Grade PTZ Camera
Model MD120UI
Request a Quote
Availability: Out of Stock
- Superb Camera Quality
- Innovative AI Technologies
- Your Privacy Matters: In any healthcare setting, it is crucial to respect patients' trust and privacy.
- Built-in Microphone for Better Real-time Monitoring
Product Overview
Overview
The AVer MD120UI is a Medical Grade PTZ Camera. Powered by advanced AI technologies, monitoring patients has become a breeze, allowing healthcare providers to stay vigilant and attentive to their patients' needs. 20X optical zoom & 4K imaging capabilities along with IR night view function provide crystal-clear visual monitoring of patients, enabling 24-hour patient monitoring with no blind spots.
Corporate AV supplies, installs and supports the AVer MD120UI across India. Request a quote for supply, installation and commissioning.
Key features
- Superb Camera Quality
- Innovative AI Technologies
- Your Privacy Matters: In any healthcare setting, it is crucial to respect patients' trust and privacy.
- Built-in Microphone for Better Real-time Monitoring
- AI Detection in Patient Ward: The MD120UI is equipped with an Edge-AI computer vision model that can automatically detect abnormal events in the ward.
- 24/7 Monitoring with Night Vision: The MD120UI has moved patient monitoring a step forward with its Infrared Night Vision function.
- Product Appearance
Why choose the MD120UI
it is a Medical Grade PTZ Camera from AVer, supplied with Corporate AV's site survey, installation and support across India, so the MD120UI is specified and set up for your space and not just shipped.
Product Highlights
Key Benefits
Superb Camera Quality
Innovative AI Technologies
Your Privacy Matters: In any healthcare setting, it is crucial to respect patients' trust and privacy.
Built-in Microphone for Better Real-time Monitoring
AI Detection in Patient Ward: The MD120UI is equipped with an Edge-AI computer vision model that can automatically detect abnormal events in the ward.
Use Cases
Ideal Applications
Large meeting rooms and boardrooms
Lecture halls, auditoriums and training rooms
Live streaming, broadcast and telehealth
Technical Details
Technical Specifications
Camera
Image Sensor
1/2.8' CMOS
Effective Picture Elements
8 Megapixels
Output Resolutions
Resolutions: 4K / 1080p / 720p; Frame Rates: 60 / 59.94 / 50 / 30 / 29.97 / 25
Minimum Illumination
0.5 lux (50 IRE, F1.6, Max. AGC, 1/30)
S/N Ratio
≥ 50 dB
Gain
Auto, Manual
TV Lines
1000 (Center / Wide)
Shutter Speed
1/1s to 1/10,000s
Exposure Control
Auto, Manual, Priority AE (Shutter, IRIS), BLC, WDR
White Balance
Auto / Manual
Optical Zoom
20X
Digital Zoom
1X
Total Zoom
20X
Viewing Angles
DFOV: 69.2° (Wide) to 4.1° (Tele); HFOV: 62.3° (Wide) to 3.6° (Tele); VFOV: 37.7° (Wide) to 2.1° (Tele)
Focal Length
f = 4.5 mm (Wide) to 90 mm (Tele)
Aperture (Iris)
F = 1.8 (Wide) to 4.7 (Tele)
Minimum Working Distance
0.1 m (Wide), 1.2 m (Tele)
Pan / Tilt Angles
Pan: ±170°, Tilt: +90° / -30°
Pan / Tilt Speed (Manual)
Pan: 0.1° to 100° / sec, Tilt: 0.1° to 100° / sec
Preset Speed
Pan: 200° / sec, Tilt: 200° / sec
Preset Positions
10 (IR), 256 (RS-232, RS-422, IP)
Camera Control - Interfaces
RS-232 / RS-422 / Ethernet
Camera Control - Protocols
VISCA (RS-232 / RS-422 / IP), CGI (IP)
Image Processing
Mirror / Flip / Freeze / WDR / BLC
Power Frequencies
50 Hz, 60 Hz
AI Function
Mode
Eye Tracking
Privacy
Protection Mode
Privacy Mode, Privacy Indicator
General
Power Requirement
12V
Power Consumption
24W
PoE
PoE+ (IEEE802.3at)
Dimensions
180(W) x 145(D) x 183.5(H) mm
Net Weight
1.7 ± 0.1 kg
Housing Material
Anti-UV
Application
Indoor
IR Night Vision
Yes
Security
Kensington Slot
IR Remote Control
Yes
Operating
Temperature: 0 °C to +40 °C; Humidity: 20% to 80%
Storage Conditions
Temperature: -20 °C to +60 °C; Humidity: 20% to 95%
Audio
Channels
2ch Stereo
Codec
AAC-LC (48K)
Built-in Microphone
1 (Omni-Directional)
Interface
Video Outputs
HDMI, IP, USB
Audio Outputs
HDMI, IP, USB
IP Streaming
Resolution
4K 60fps
Network Video Compress Formats
H.264, H.265, MJPEG
Maximum Frame Rate
4K 60fps
Bit-Rate Control Modes
VBR, CBR
Range of Bit-Rate
512Kbps to 64Mbps
Network Interface
10 / 100 / 1000 Base-T
Multi-Stream Capability
2 (RTSP / Web page), 4K 60fps Max.
Network Protocols
IPv6, IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, DHCP RTP/RTCP, RTSP, RTMP,VISCA over IP
USB
Connector
USB 3.0 (Type-B)
Video Formats
MJPEG
Maximum Video Resolution
2160p
USB Video Class (UVC)
UVC 1.1
USB Audio Class (UAC)
UAC 1.0
Web UI
Live Video Preview
Yes
Camera PTZ Control
Pan, Tilt, Zoom, Focus, Preset Control
Camera / Image Adjustment
Exposure, White Balance, Picture
Network Configuration
DHCP, IP Address, Gateway, Subnet Mask, DNS
Software Tools
IP Search and Configuration Tool
Support Windows 7 or later
ViewCare
Support Windows 7 or later
PTZ Control Panel
Supports iOS & iPadOS 11 or later
Camera Setting Tool
Supports Windows 7 or later, macOS 10.14 or later
Warranty
Camera
3 Years
Accessories
1 Year
Specifications
Package Contents
Camera, Remote Control, Power Adapter, Power Cord, USB 3.0 Type-A to B Cable (1.5m), 1/4"-20 L=6.5 mm Screw (x2), M2 x 4 mm Screw (x3), M3 x 6 mm Screw (x3), Drilling Paper, Ceiling Mount
Optional Accessories
AVer CL01 PTZ Camera Controller, L-Type Wall Mount
Why CorporateAV?
Sourced right. Installed right.
Genuine Manufacturer Stock
Every unit sourced through authorized distribution, backed by manufacturer warranty.
Expert AV Integration
Paired correctly with compatible systems and your room's existing AV infrastructure.
Pan-India Delivery & Support
On-site installation and ongoing technical support wherever your project is based.
More Details
Additional Information
Why Buy The MD120UI From Corporate AV?
- Genuine AVer stock with manufacturer warranty support
- Custom pricing for bulk and multi-room / multi-site rollouts
- Local after-sales support — a real team you can call or WhatsApp, not a call centre
- Expert guidance on product selection and deployment planning
- Professional installation across Bangalore, Hyderabad, Mumbai, Delhi NCR, and the wider India region
Distribution
Corporate AV supplies and installs AVer products across Bangalore, Hyderabad, Mumbai, Delhi NCR, Chennai, Pune, Kolkata, Ahmedabad, and the wider India region.
Frequently Asked Questions
What is the AVer MD120UI?
The AVer MD120UI is a Medical Grade PTZ Camera. Powered by advanced AI technologies, monitoring patients has become a breeze, allowing healthcare providers to stay vigilant and attentive to their patients' needs. 20X optical zoom & 4K imaging capabilities along with IR night view function provide crystal-clear visual monitoring of patients, enabling 24-hour patient monitoring with no blind spots.
Who is the AVer MD120UI best suited for?
The MD120UI suits large meeting rooms and boardrooms, lecture halls, auditoriums and training rooms and live streaming, broadcast and telehealth. Corporate AV can advise whether it is the right fit for your room or classroom.
What are the key specifications of the AVer MD120UI?
AVer lists these key specifications for the MD120UI. Image Sensor: 1/2.8' CMOS. Effective Picture Elements: 8 Megapixels. Minimum Illumination: 0.5 lux (50 IRE, F1.6, Max. AGC, 1/30). S/N Ratio: ≥ 50 dB.
What are the main features of the AVer MD120UI?
AVer highlights superb camera quality; innovative ai technologies; your privacy matters; built-in microphone for better real-time monitoring on the MD120UI.
Can Corporate AV supply multiple AVer MD120UI units for a rollout?
Yes. Corporate AV supplies and integrates the AVer MD120UI in single units and multi-room rollouts across India, with a site survey, installation, commissioning and support.
How do I get a quote for the AVer MD120UI in India?
Use the Request a Quote button on this page or contact Corporate AV with your room details and quantity, and a consultant will respond with a quotation for supply and installation.
